Elitech IR-200 Infrared & Heated Diode Refrigerant Leak Detector for Air Conditioner and Automotive Repair
Featured with TFT screen, Elitech IR-200 detects leaks as small as 4 grams/yr (0.14 oz/yr). It has three sensitivity settings to keep false triggering to a minimum. A quick and automatic 30-second self-calibration upon power-up ensures optimal performance. It comes with a rechargeable and removable lithium-ion battery which powers the IR-200 for 8 hrs of continuous operation before a recharge is needed.
Key Feature
- Suitable for more refrigerant, including HFCs, HCs, HCFCs, CFCs, HFO-1234
- Locate range and fixed-point, applicable to any complex conditions
- Real-time display of concentration curve and peak recording
- Lower power consumption and longer battery life
- High-performance sensor tip, avoid water ingress
- 10 minutes auto-off
- 2 Year's Warranty
Specification
| Refrigerants | CFCs, HFCs, HCFC series and HFO-1234YF |
| Sensor Life |
Infrared Sensor: 10 Years; Heated Diode Sensor: 500 Hours |
| Sensitivity |
Infrared Sensor: up to 4g/year; Heated Diode Sensor: up to 13g/year |
| Sensors | Infrared & Heated Diode |
| Alarm Mode | Audible & Visual Alarm |
| Auto-Off | After 10 min of inactivity |
| Power Supply | 2 * 18650 lithium battery |
| Operating Hour | 8 hours continuously (after a single charge) |
| Charging Time | Approx. 4 hrs |
| Charging Voltage/Current | DC 5V, 1A |
| Storage Temperature | -20℃~60℃ (-4℉~140℉) |
| Operating Temperature | -10℃~52℃ |
| Operating Humidity | Maximum 90%RH (non-condensing) |
| Certifications | CE, EN14624:2012, RoHS, SAE_J1627, SAE_ J2791, SAE_J2913 |
| Dimensions | 201 x 72 x 35mm(7.9”x2.8” x1.4”) |
| Weight | 450g (15.9oz) |
| Warranty | 2 years |
Refrigerants
| Type | Details |
| CFCs | R11、 R12、 R13、 R502、 R503 |
| HCFCs | R22、 R123、 R124、 R141b、 R142b、 R402A、 R402B、 R408A、 R409A |
| HFCs | R134a、 R410A、 R407C、 R417A、 R404A、 R507、 R23、 R508A、 R508B、 R152a |
| Blends | AZ-50. HP62. MP39,etc. |
| HC | R170、 R290、 R600a、R1270 |
| PFC | PFC-14、 PFC-116、 PFC-218 |
| HFO-1234 | |
| C2H4F2 | R152a Difluoroethane |
Please kindly note that for HC refrigerants, it just can be used for small household appliances.
What's Included
- 1 x Leak Detector
- 1 x UV LED
- 1 x User Manual (Download)
- 1 x Plastic Case
- 1 x Adapter
- 1 x Charging Cable
- 5 x Replacement Filter
- 1 x Replacement Probe
Filter Replacement
The filter can block large particle contaminants and moisture to reduce false alarms caused by excessive humidity. Please replace the filter in time when it is seriously polluted (black and clogged).
[Custom Product Tab]
User Manual: Download
Elitech HVAC Tools Catalog Brochure: Download
Instruction Video:
[/Custom Product Tab]
